The visual positioning technology used in the dispenser relies primarily on high-definition camera systems and advanced image processing and analysis algorithms. The following is a specific introduction to the visual positioning of the dispensing machine:
First, the composition of the visual positioning system
1. HD camera system:
Dispensers are generally equipped with high-definition cameras to capture the image information of the workpiece to be dispensed.
The camera should have a high resolution and a fast response ability to guarantee image clarity and capture speed.
2. Light source:
Provide the camera with sufficient lighting to ensure image quality.
The choice of light source should be adjusted according to the material, color and reflection characteristics of the workpiece.
3. Image Processing Software:
Processing and analysis of images captured by the camera, including image enhancement, filtering, marginal detection, etc.
The algorithm identifies the dispensing position on the workpiece and calculates the accurate dispensing coordinates.
Second, the function of the visual positioning system
1. Automatic Identification and Positioning:
The visual positioning system can automatically identify the dispensing position on the workpiece without manual intervention.
Through the image processing algorithm, the system can accurately calculate the dispensing coordinates and complete the high-precision positioning.
2. Real-time monitoring and adjustment:
During the dispensing process, the visual positioning system can monitor the activity status and dispensing effect of the glue in real time.
According to the real-time monitoring results, the system can automatically adjust the movement speed and dispensing amount of the manipulator to ensure that the glue is evenly applied.
3. Collaborative Operation:
In the multi-robot dispensing system, the visual positioning system can complete the collaborative operation between multiple robots.
By sharing the orientation and posture information of policy objects in real time, multiple manipulators can carry out dispensing operations at the same time, improving the production power.
The visual positioning technology used in the dispensing machine completes the dispensing operation of high precision, high speed and intelligent positioning through the collaborative operation of high-definition camera system, light source and image processing software. This technology is widely used in various industries and provides strong support for modern industrial production. Dongguan Nasheng Electronic Equipment Technology Co., Ltd. has been established for more than 10 years, focusing on the planning and production of visual dispensing machines, which can be used for UV glue, yellow glue, silicone, anaerobic glue, Fan Li water, black glue, sealant, AB glue, paint, ink dispensing, free proofing, want to know more: find "Nasheng visual dispensing machine" for consultation.
