1. It is equipped with over-current protection, over-temperature protection and over-voltage protection circuits.
2. The isolation transformer step-up mode is adopted, and the high-voltage circuit is completely isolated from the low-voltage circuit.
3. Fast magnetization, stable performance, multiple protection, 24 hours of continuous work.
model：NS-MI.3050，NS-MI.30100，NS-MI.30150
input power：AC220V-55A、AC380V-50A，AC380V-50A，AC380V-50A
Magnetizing volta ge：DC2000V/DC0V~3000V
Output current：15K~60KA，60K~80KA
Capacitance：5000UF，10000UF，15000UF
Discharge energy：22500J，45000J,675000J
Charging time：5S,7.5S,10S
Main control element：SCR
Dimensions：720*900*1400mm，720*900*1400mm，720*1300*1400mm
weight：Approx. 380kg，Approx. 460kg，Approx. 550kg，
Remark：
1. The above conventional models accept special customization! (The product is constantly innovating, if there is any change, the actual product shall prevail)
2. Optional "demagnetization" function (suffix D), dual output function (suffix B)
