1. It is equipped with over-current protection, over-temperature protection and over-voltage protection circuits.
2. The isolation transformer step-up mode is adopted, and the high-voltage circuit is completely isolated from the low-voltage circuit.
3. Fast magnetization, stable performance, multiple protection, 24 hours of continuous work.
model：NS-MI.2520，NS-MI.2530，NS-MI.2540，NS-MI.2550，NS-MI.2560
input power：AC220V-55A、AC380V-50A，AC220V-55A、AC380V-50A，AC220V-55A、AC380V-50A，AC220V-55A、AC380V-50A，AC220V-55A、AC380V-50A
Magnetizing volta ge：DC2500V/DC50V~2500V
Output current：15K~35KA
Capacitance：2000UF，3000UF，4500UF，5000UF，6000UF
Discharge energy：6250J，9375J，12500J，15625J，18750J
Charging time：2S,3S,3.5S,4S,5S
Main control element：SCR
Dimensions：720*900*1400mm
weight：Approx. 250kg，Approx. 280kg，Approx. 320kg，Approx. 360kg，Approx. 380kg
Remark：
1. The above conventional models accept special customization! (The product is constantly innovating, if there is any change, the actual product shall prevail)
2. Optional "demagnetization" function (suffix D), dual output function (suffix B)
