1. It is equipped with over-current protection, over-temperature protection and over-voltage protection circuits.
2. The isolation transformer step-up mode is adopted, and the high-voltage circuit is completely isolated from the low-voltage circuit.
3. Fast magnetization, stable performance, multiple protection, 24 hours of continuous work.
model：NS-M1.2020，NS-M1.2040，NS-M1.2050
input power：AC220V-55A、AC380V-50A，AC220V-55A、AC380V-50A，AC220V-55A、AC380V-50A
Magnetizing volta ge：DC2000V/DC0V~2000V
Output current：15K~35KA
Capacitance：2000UF，4000UF，5000UF
Discharge energy：4000J，8000J,10000J
Charging time：2S,3S,3.5S
Main control element：SCR
Dimensions：520*1000*1200mm
weight：Approx. 160kg
Remark：
1. The above conventional models accept special customization! (The product is constantly innovating, if there is any change, the actual product shall prevail)
2. Optional "demagnetization" function (suffix D), dual output function (suffix B)
