1. Customize the vibrating plate according to the special-shaped magnet product, and use various products such as square, tile, and rectangle by adjusting the vibrating plate to reduce equipment investment;
2. Tunnel magnetizing table, with high-performance magnetizer, the tunnel length is greater than the length of the slitting magnet, with the control software, to ensure that each magnet can be saturated and magnetized;
3. Fast magnetization, stable performance, multiple protection, 24 hours without shutdown, continuous work
Magnetizing machine model：Special magnetizer for permanent magnets
Ice water machine model：NS.BS.100
Applicable magnet size：Magnetization: φ2.0~φ12mm, length: 3.0~15mm (diameter less than length)
working efficiency：>6000PCS/HOUR. (Efficiency is affected by magnet size differences)
charged Gaussian：>3500J
MODE：Touch screen/PC
Input power supply：Magnet automatic magnetization swinging equipment: AC 110V/220V 50~60Hz; Magnetizing machine: AC 380V 50~60Hz
Power (W)：Magnet automatic magnetization swinging plate equipment: 300w. Magnetizer: 8000J. Water chiller: 900W
Working environment (temperature/humidity)：5 – 40 °C/20 – 90% non-condensing
Body weight (kg)：Magnet automatic magnetization swing plate equipment: 160KG. Magnetizing machine: 260KG. Water chiller: 35KG
