1. Double-pass to the tunnel magnetization table, and complete the forward and reverse magnetization of two strings of magnets at one time, with high performance
It can be magnetized to ensure the magnetization effect;
2. The double feeding line runs separately and does not interfere with each other;
3. The automatic pushing mechanism cooperates with the detection of light brazing to accurately push the material;
4. Lengthen the flow channel to avoid magnetization interference with the pusher arrangement, and the flange limit is adjustable, which is not applicable
Magnets of the same shape and model
Magnetizing machine model：Special magnetizer for permanent magnets
Ice water machine model：NS.BS.100
Applicable magnet size：Magnet length: 14~30mm, magnet width: 5~14mm, magnet thickness: 1~5mm (square/tile magnet)
working efficiency：More than 8000PCS/hour. (Efficiency is affected by magnet size differences)
charged Gaussian：>3500J
MODE：Touch screen/PC
Input power supply：Magnet automatic magnetization swing plate equipment: AC 110V/220V 50~60Hz. Magnetizing machine: AC 380V 50~60Hz
Power (W)：Magnet automatic magnetization swinging plate equipment: 300w. Magnetizer: 8000J. Water chiller: 900W
Working environment (temperature/humidity)：5 – 40 °C/20 – 90% non-condensing
Body weight (kg)：Magnet automatic magnetization swing plate equipment: 160KG. Magnetizing machine: 450KG. Water chiller: 35KG
